NetPeppers OPM100 Optical Power Meter
SKU:
SKU: OPM-150
Category:
OTDR & OLS
Hardware
The NetPeppers OPM100 is a handheld optical power meter for measuring optical power levels in access and telecommunications fiber optic networks. Used with the OLS150 stabilized light source it enables accurate insertion loss measurement on singlemode and multimode fiber. Calibrated wavelengths: 850, 1300, 1310, 1490, 1550 and 1625 nm. Measurement range -70 to +10 dBm. InGaAs detector with 0.01 dB resolution. Battery life exceeds 25 hours. FC connector interchangeable with SC and ST. Includes 1 interchangeable adapter SC/ST and quick start guide.
Unite Price
POA
Price on Application — contact us for a quote
1
Description
The NetPeppers OPM100 is a handheld optical power meter for measuring optical power levels in access and telecommunications fiber optic networks. Used with the OLS150 stabilized light source it enables accurate insertion loss measurement on singlemode and multimode fiber. Calibrated wavelengths: 850, 1300, 1310, 1490, 1550 and 1625 nm. Measurement range -70 to +10 dBm. InGaAs detector with 0.01 dB resolution. Battery life exceeds 25 hours. FC connector interchangeable with SC and ST. Includes 1 interchangeable adapter SC/ST and quick start guide.
6 calibrated wavelengths: 850, 1300, 1310, 1490, 1550 and 1625 nm
Measurement range -70 to +10 dBm with 0.01 dB resolution and InGaAs detector
Displays in W, mW, uW, dBm and dB with reference memory for loss measurement
FC connector interchangeable with SC and ST. Battery life exceeds 25 hours
Includes 1 interchangeable SC/ST adapter and quick start guide
